膜寬（毫米）
Film width (mm)
|
100~320
|
|
制袋尺寸（毫米）長*寬
Bag size (mm) length * width
|
50*40~200*150
|
|
卷材直徑（毫米）
Roll diameter (mm)
|
≤300
|
|
包裝速度（袋/分鐘）
The packing speed (bags / minute)
|
30~60
|
|
電源總功率（千瓦）
Total power (kw)
|
1.5 kW 220/380 V±10% 50 Hz
|
|
機器尺寸（厘米）長*寬*高
Machine size (CM) length * width * height
|
90*70*170
|
|
整機重量（千克）
Machine weight (Kg)
|
300
|
|
氣源
Gas source
|
5-7Mpa
|
適用范圍：
Scope of application:
適用于顆粒狀、粉體狀、液體狀、短條狀、片狀物品的包裝。如：膨化食品、蝦條、花生、爆米花、麥片、瓜子、調味粉等物料的三角袋立體包裝。
Suitable for granular, powder, liquid, strip, sheet materials packaging. Such as: Triangle bag solid packing puffed food, shrimp, peanuts, popcorn, melon seeds, cereal, seasoning powder and other materials.
功能特點：
Function characteristics:
1、采用先進的微電腦控制器，步進驅動電機控制袋長及商標定位，性能穩(wěn)定、調整方便、檢測準確。
2、可自動完成制袋、計量、充填、封合、分切、計數、打印批號等功能。
3、包裝外觀獨特呈三角形狀，美觀、時尚。
1, adopt advanced microcomputer controller, stepper motor drive and control the length of bag, stable performance, convenient adjustment, accurate detection.
2, can be completed automatically bag making, measuring, filling, sealing, cutting, counting, print a batch number etc..
3, packaging appearance unique triangular shape, appearance, fashion.
